Description

**IN STOCK FOR IMMEDIATE DELIVERY** (1x Available as at 01-Sep-2021)



Pulsar Thermion XM30 Thermal Scope







Highly sensitive thermal imaging sensor

Thermal imaging sensor with NETD <25mK* ensures perfect detail recognition even in the harshest weather conditions with low thermal contrast. The smallest temperature differences will be clearly visible during rainfall, in fog or cold mornings in the most difficult conditions for thermal imaging.

* - Thermion 2 XP50

Fast Aperture F/1.2 Germanium Optics

Quality fast-aperture germanium optics ensure optimal heat energy transmissivity minimizing noise and improving the details of the scene observed.



Mounts on Standard 30 mm Scope Rings

Designed from the ground up for ease of use, Thermion riflescopes are mounted on standard 30mm scope rings. No specialized tools or equipment are required.

New Pulsar Thermion 2 XP50 Ring Mounts

Long Detection Range 1300 m (1,420 Yds)

High quality germanium optics coupled with an advanced thermal imaging sensor ensure an unprecedented detection range of up to 1300 meters – even in complete darkness.



Recoil Rated up to .375 H&H, 12-Gauge and 9.3x64

Recoil rated up to 6,000 joules for flawless performance on larger calibers up to .375 H&H, 12-gauge and 9.3x64.

New Pulsar Thermion 2 XP50  Recoil Rated up to .375 H&H, 12-Gauge and 9.3x64

Rugged, Reliable All-Metal Housing

Designed for rugged reliability, Thermion riflescopes boast full, reinforced yet lightweight мetal construction. Precision-fabrication of housing elements ensures flawless field performance.

IPX7 Waterproof Rated

IPX7 waterproof rated for protection from heavy rainfall, snow or other precipitation. The Thermion is designed to run flawlessly, even after submersion in up to 3 feet of water for up to 30 minutes.

 New Pulsar Thermion 2 XP50  IPX7 Waterproof Rated

Variable Digital Zoom

Digital zoom, up to 8x, provides improved focus and overall target recognition at significant distances.

New Pulsar Thermion 2 XP50 Variable Digital Zoom

Customizable Reticle Options

Wide array of color-customizable reticles, including scalable ballistic styles. Color options: black, white, red and green.

New Pulsar Thermion 2 XP50 Customizable Reticle Options

Picture-in-Picture

Picture-in-picture displays a magnified image at the top-center 10% of the overall field of view for precise shot placement.

New Pulsar Thermion 2 XP50 Picture-in-Picture

Zeroing Profiles Management

Store up to 5 zeroing profiles, with 10 distance coordinates each for varying scenarios, in internal memory for quick rifle change-outs and on-the-fly adjustments.

Image Boost Technology

Image Boost technology is a proprietary combination of software algorithms which enhance image clarity and overall image detail. Applying Image Boost makes for a sharper and more detailed picture enabling better object identification capabilities.

New Pulsar Thermion 2 XP50 Image Boost Technology

Full-Color, HD AMOLED Display

While the Thermion’s HD AMOLED display delivers crisp, richly contrasted, vividly colored field of view, AMOLED technology ensures flawless, fluid, high-resolution imaging and power saving.

New Pulsar Thermion 2 XP50 Full-Color, HD AMOLED Display

Color Palettes

Color palettes offer customized display options. While white hot and black hot are most popular, red hot, rainbow and ultramarine highlight a heat signature’s more intense hot spots. Violet, red monochrome and sepia are optimal palettes for reduced eye fatigue over long periods of observation.

New Pulsar Thermion 2 XP50 Color Palettes



B-Pack Mini Combined Power System

Thermion riflescopes have a combined battery system which consists of two rechargeable batteries – internal and external. The external rechargeable battery ensures additional operation time and can be replaced in a matter of seconds.

Upgradable Functionality

Functions and features of Thermion models as well as their performance can be upgraded and improved with the release of new software.

User Friendly Controls

Thermion operation and adjustments are simple using the three function buttons on the top of the device and left side encoder. The three buttons and encoder provide access and management of all device menu options, settings, and system functions.



Pulsar Specifications

  Main Thermion XM30
Sensor
320x240 @ 12 µm (NETD <50 mK)
Objective lens
F30/1.2
Magnification, x
3.5 – 14 (x4 zoom)
Field of view (HxV), degrees / m@100m
7.3x5.5 / 12.8x9.6
Detection range, m
1300
  Sensor

Type
uncooled
Resolution, pixels
320x240
Pixel pitch, µm
12
NETD, mK
<50
Frame rate, Hz
50
  Optics

Objective lens
F30/1.2
Magnification, x
3.5 - 14
Field of view (HxV), degrees / m @ 100 m
7.3x5.5 / 12.8x9.6
Eye relief, mm
50
  Display

Type
AMOLED HD
Resolution, pixels
1024x768
  Range Performance

Detection range, m
1300
  Reticle

Click value, H/V, mm at 100 m
12 / 12 (on minimum magnification)
Click range, H/V, mm at 100 m
2400 / 2400
Number of preloaded reticles
10
  Video Recorder

Video / photo resolution, pixel
1024x768
Video / photo format
mp4 / .jpg
Built-in memory, Gb
16
  Environmental Characteristics

Degree of protection, IP code (IEC60529)
IPХ7 (waterproof)
Operating temperature range, °C
-25 – +50
  Power Supply

Output voltage, V
3.0 - 4.2
Battery type
Dual Li-Ion B-Pack Mini Power System: 2 A·h Changeable Battery (external) / 3.2 A·h Battery (internal)
Capacity, mAh
2000 (external) + 3200 (internal)
Operating time on battery pack (at t=22°C), h *
7
External power supply, V
5 (Micro USB Type B)
  Connections and Compatibilities

Max. recoil power on rifled weapon (Eo), Joules
6000
Shock resistance on the smooth-bore rifles, caliber
12
Mounting brackets on weapon
Standard 30 mm rings
  Wi-Fi

Frequency, GHz
2.4GHz
Standard
802, 11 b/g
Line-of-sight reception range m
15
  Weight & Size

Body Material
Metal
Dimensions mm
387x78x74
Weight kg
0.75
  Warranty

Warranty on Device, years
3
Warranty on Batteries, years
1
  Trade Data

SKU (Model #)
76524





Optoelectronic Devices & Batteries Compatibility Chart









Extra Information

Brand:
Pulsar

Warranty Information

Pulsar Products have a 3 year warranty with the exception of Pulsar batteries which have a warranty of 1 year from purchase.
