HIKMICRO Lynx 2.0 LH19 Thermal Monocular
Featuring a supremely sensitive 384px sensor with a NETD < 20mK, the HIKMCRO LYNX LH19 2.0 guarantees the creation of vibrant and intricate images. Take command with its manual focus capability, enabling precise adjustments to the image according to your preferred distance.
Key Features
- High sensitivity thermal module NETD < 20 mK (@25°C, F# = 1.0)
- 384 × 288 resolution with 12μm detector
- 1024 × 768 resolution 0.39-inch OLED display
- Replaceable and rechargeable Li-ion battery
- 280 g lightweight, with a compact and ergonomic design
- Up to 6.5 hours of continuous operation
Range Specifications
|
Model
|
LH15 2.0
|
LH19 2.0
|
LH25 2.0 Pro
|
|
Sensor
|
VOx Uncooled Focal Plane Arrays
|
VOx Uncooled Focal Plane Arrays
|
VOx Uncooled Focal Plane Arrays
|
| Objective Lens |
15mm, f1.0
|
19mm, F1.0
|
25mm, F1.0
|
|
Magnification, x
|
1.4x-11.2x (8x)
|
1.8x-14.4x (8x)
|
2.4x-19.2x (8x)
|
|
Field of view (HxV), degrees / m@100m
|
17.5°×13.1°/30.8m×23.0m
|
13.7°×10.3°/24.0m×18.0m
|
10.5°×7.9°/18.4m×13.8m
|
|
Detection range, m (thermal)
|
750m
|
900m
|
1200m
|
|
Sensor
|
|
|
|
|
Type
|
VOx Uncooled Focal Plane Arrays
|
VOx Uncooled Focal Plane Arrays
|
VOx Uncooled Focal Plane Arrays
|
|
Resolution, pixels
|
384x288
|
384x288
|
384x288
|
|
Pixel pitch, µm
|
12μm
|
12μm
|
12μm
|
|
NETD, mK
|
Less than 20 mK (@25°C),F#=1.0
|
Less than 20 mK (@25°C),F#=1.0
|
Less than 20 mK (@25°C),F#=1.0
|
|
Frame rate, Hz
|
50Hz
|
50Hz
|
50Hz
|
|
Optics
|
|
|
|
|
Objective lens
|
15mm, f1.0
|
19mm, F1.0
|
25mm, F1.0
|
|
Magnification, x
|
1.4x-11.2x (8x)
|
1.8x-14.4x (8x)
|
2.4x-19.2x (8x)
|
|
Field of view (HxV), degrees / m @ 100 m
|
17.5°×13.1°/ 30.8m×23.0m
|
13.7°×10.3°/24.0m×18.0m
|
10.5°×7.9°/18.4m×13.8m
|
|
Eye relief, mm
|
20mm
|
20mm
|
20mm
|
|
Display
|
|
|
|
|
Type
|
OLED
|
OLED
|
OLED
|
|
Resolution, pixels
|
1024x768, 0.39 inch
|
1024x768, 0.39 inch
|
1024x768, 0.39 inch
|
|
Range Performance
|
|
|
|
|
Detection range, m (thermal)
|
750m
|
900m
|
1200m
|
| Laser Rangefinder | - | - | - |
|
Safety Class for laser equipment according IEC 60825-1:2014
|
-
|
-
|
-
|
|
Wavelength, nm
|
-
|
-
|
-
|
|
Max. measuring range, m
|
-
|
-
|
-
|
|
Measurement Accuracy, m
|
-
|
-
|
-
|
|
Min. Measuring Range
|
-
|
-
|
-
|
|
Click value, H/V, mm at 100 m
|
-
|
-
|
-
|
|
Click range, H/V, mm at 100 m
|
-
|
-
|
-
|
|
Number of preloaded reticles
|
-
|
-
|
-
|
|
Video Recorder
|
|
|
|
|
Video / photo resolution, pixel
|
|
|
|
|
Video / photo format
|
|
|
|
|
Built-in memory, Gb
|
Built-in EMMC (16 GB)
|
Built-in EMMC (16 GB)
|
Built-in EMMC (16 GB)
|
|
Wi-Fi
|
|
|
|
|
Wireless Protocol
|
|
|
|
|
Wireless Standard
|
|
|
|
|
Frequency, GHz
|
|
|
|
|
Environmental Characteristics
|
|
|
|
|
Degree of protection, IP code (IEC60529)
|
IP67
|
IP67
|
IP67 |
|
Operating temperature range, °C
|
-30°C to +55°C
|
-30°C to +55°C
|
-30°C to +55°C
|
|
Connections and Compatibilities
|
|||
|
Max. recoil power on rifled weapon (Eo), Joules
|
|||
|
Shock resistance on the smooth-bore rifles, caliber
|
|||
|
Mounting brackets on weapon
|
|||
|
Supported Appplication
|
|
|
|
|
Power Supply
|
|
|
|
|
Output voltage, V
|
|
|
|
|
Battery type
|
Replaceable and Rechargeable Li-ion Battery
|
Replaceable and Rechargeable Li-ion Battery
|
Replaceable and Rechargeable Li-ion Battery
|
|
Capacity, mAh
|
|||
|
Operating time on battery pack (at t=22°C), h *
|
6.5-hour continuous running with CVBS and hotspot function off (@25°C)
|
6.5-hour continuous running with CVBS and hotspot function off (@25°C)
|
6.5-hour continuous running with CVBS and hotspot function off (@25°C)
|
|
External power supply, V
|
5V DC, 2 A Supports External Power Supply |
5V DC, 2 A Supports External Power Supply |
5V DC, 2 A Supports External Power Supply |
|
Weight & Size
|
|||
| Body Material | |||
|
Dimensions mm
|
164.0mm × 56.0mm× 60.8mm
|
172.5mm × 56.0mm× 60.8mm
|
172.5mm × 56.0mm× 60.8mm
|
| Weight |
272g without battery
|
282g without battery
|
277g without battery
|
|
Warranty
|
|||
|
Warranty on Device, years
|
3 years | 3 years | 3 years |
|
Warranty on Batteries, years
|
1 year | 1 year | 1 year |
|
Trade Data
|
|||
|
SKU (Model #)
|
TIHIK507 | TIHIK508 | TIHIK506 |
Sub-20mK High Sensitivity Brings Detailed and Informative Images
With high sensitivity (NETD<20mK), the HIKMICRO LYNX 2.0 thermal monocular delivers detailed and informative images under all weather conditions.
Advanced Design for Great Operating Convenience
Double-Charging Method and Fast Boot-On Bring More Lasting Use
· The innovation of HIKMICRO LYNX 2.0 design is reflected in the power supply design. A replaceable and rechargeable battery can support 6.5 hours of continuous running. Moreover, the battery can charge both in the device and the battery charger. Plug and go.
· Fast boot within 3s makes HIKMICRO LYNX 2.0 always ready for use.
Software Revolution Brings a More Comfortable Visual Experience.
Personalized Settings Available to Enhance Visual Experience
The HIKMICRO LYNX 2.0 thermal monocular is characterized by the hierarchical menu, prioritizing frequently used functions according to user habits. Users can customize and improve their visual experience by adjusting settings such
Auto Screen Off Darkens the Screen to Save Energy and Increase Battery Time
The integrated algorithm automatically detects HIKMICRO LYNX 2.0’s exact position and activates the auto screen-off function. HIKMICRO LYNX 2.0 will stand by automatically at a lateral tilt of 75°as well as at a downward or upward tilt of 70°.
Sharing Your Exciting Moments
The integrated hotspot module makes the HIKMICRO Sight app a second display. Users can adjust the main parameters of HIKMICRO LYNX 2.0 thermal monocular, capture thrilling moments, and share them to social media immediately.
More Advantages
