Pulsar Merger DUO NXP50 Multispectral Binoculars

SKU:
77455
$8,999.00

Free Express Shipping

Description

Pulsar Merger DUO NXP50 Multispectral Binoculars

The Merger Duo NXP50 redefines multispectral binoculars by seamlessly integrating thermal and digital night vision imaging into one compact unit, elevating detection, recognition, and identification capabilities. With its ability to capture high-quality images across various wavelength spectrums—visible, near-infrared, and long-wave infrared—the Merger Duo NXP50 ensures optimal observation regardless of the time of day or weather conditions. By harnessing the strengths of both technologies, it simplifies object location with thermal imaging, provides terrain assessment with digital night vision, and offers clear identification of even the smallest features through combined viewing modes. Experience unparalleled versatility and performance with the Merger Duo NXP50.

Key Features

  • Thermal, digital and combined viewing modes
  • Highly sensitive 640x480 pixel @ 17 µm thermal imaging sensor with NETD <25mK
  • Extra low-light Full-HD digital night vision
  • Advanced Pulsar Image boost technology
  • Fast aperture F50/1.0 thermal lens
  • Invisible IR Illuminator for image detail increase in digital channel
  • High-contrast HD AMOLED displays
  • A selection of 8 colour palettes in thermal mode
  • 1800m thermal detection range
  • Comfortable viewing experience
  • Convenient classic binocular design
  • Built-in photo and video recorder
  • Dual battery system
  • Proximity sensor for covert use
  • Ergonomic and functional carrying case
  • Stream Vision 2. Wi-Fi integration with iOS and Android devices
  • Dual Wi-Fi waveband support 2.4 / 5 GHZ
  • Magnesium alloy housing
  • IPX7 submersion waterproof rated
  • Operation in extreme temperatures -25 to +50°C

Range Specifications

Model
Merger Duo NXP50
Sensor
640x480 pix. @ 17 µm (thermal) | CMOS 1920x1200 (digital)
Objective Lens
F50/1.0 (thermal) | F50/1.4 (digital)
Magnification, x
3 – 24 (thermal) | 2 – 16 (digital)
Field of view (HxV), degrees / m@100m
12.4°/ 21.8 m (thermal) | 17.5°/ 30.7 m (digital)
Detection range, m (thermal)
1800 (thermal detection)
  Sensor

Type
CMOS
Resolution, pixels
1920x1200
Pixel pitch, µm
17 (thermal)
NETD, mK
<25 (thermal)
Frame rate, Hz
50
  Optics

Objective lens
F50/1.0 (thermal) | F50/1.4 (digital)
Magnification, x
3 – 24 (thermal) | 2 – 16 (digital)
Field of view (HxV), degrees / m @ 100 m
12.4°/ 21.8 m (thermal) | 17.5°/ 30.7 m (digital)
Eye relief, mm
12
  Display

Type
Uncooled, microbolometric (thermal) | Full-HD CMOS (digital)
Resolution, pixels
640x480 pix. @ 17 µm (thermal) | CMOS 1920x1200 (digital)
  Range Performance

Detection range, m (thermal)
1800 (thermal detection)
  Laser Rangefinder
Safety Class for laser equipment according IEC 60825-1:2014

Wavelength, nm

Max. measuring range, m

Measurement Accuracy, m

Min. Measuring Range

Click value, H/V, mm at 100 m

Click range, H/V, mm at 100 m

Number of preloaded reticles

  Video Recorder

Video / photo resolution, pixel
1280х960
Video / photo format
.mp4 / .jpg
Built-in memory, Gb
64 GB
  Wi-Fi

Wireless Protocol
Wi-Fi
Wireless Standard
IEEE 802.11 b/g/n/ac (WPA)
Frequency, GHz
2.4 / 5
  Environmental Characteristics

Degree of protection, IP code (IEC60529)

Operating temperature range, °C

  Connections and Compatibilities

Max. recoil power on rifled weapon (Eo), Joules

Shock resistance on the smooth-bore rifles, caliber

Mounting brackets on weapon

Supported Appplication

  Power Supply

Output voltage, V
3.0 – 4.2
Battery type
Dual Li-Ion power system: APS 3 changeable battery (3.2 A·h) and built-in battery pack (4.0 A·h)
Capacity, mAh
3200 (external) + 4000 (internal)
Operating time on battery pack (at t=22°C), h *
7.5
External power supply, V
5V, 9V (USB Type-C Power Delivery)
  Weight & Size

Body Material
Magnesium alloy
Dimensions mm
207x140x73
Weight
1.2 (batteries included)
  Warranty

Warranty on Device, years

Warranty on Batteries, years

  Trade Data

SKU (Model #)
77455

Thermal, digital and combined viewing modes

The Merger Duo supports several observation modes. The thermal image mode is used for animal detection and observation in any weather conditions, while digital image mode maintains improved target-identification capability in Full-HD resolution. The “Picture-in-Picture” function makes it possible to simultaneously display images from both optical channels, prioritising the thermal or digital image.

Highly sensitive thermal sensor

Highly sensitive 640x480 pixel @ 17 µm thermal imaging sensor with NETD <25mK ensures stunning thermal image quality and perfect detail recognition even in the hardest weather conditions, when thermal contrast is low. The smallest temperature differences will be clearly visible during the rainfall, fog or cold mornings, in the most difficult conditions for thermal imager.

Extra low-light Full-HD digital night vision

The image generated by the Merger Duo NXP50 digital night channel features high definition and high-quality detail processing. Silhouettes, anatomical differences, behavioral peculiarities – HD-resolution electronics display the trophy qualities of an animal, giving the hunter the information needed for good decision-making on a shot.

IR illuminator

The Merger Duo NXP50 comes with an attachable invisible 940 nm IR illuminator with adjustable spot positioning. It increases the image detail in the digital channel during a pitch-black night.

User mode

Use the brightness and contrast adjustments to maximise the detail and informative value of the image in specific observation conditions. The User Mode function saves selected brightness and contrast settings in the device's memory providing optimal image quality for the next use of the thermal imager immediately, with no additional adjustments needed.

Image. Quality

Advanced Pulsar Image boost technology

Advanced Pulsar Image boost technology

Pulsar Image Boost gives Merger Duo thermal imaging the highest level of detail, clarity and contrast with a set of original image processing algorithms. Merger Duo multispectral binoculars render complex scenes in a wide range of halftones with evenly emitting low-contrast objects, such as the sky, grass and water surfaces. Software detailing and sharpening of objects at different distances makes the thermal image highly informative. Manually increasing the thermal imaging sensor sensitivity improves the quality of animal detection when observation conditions worsen. A smoothing filter and a wide range of brightness and contrast settings make prolonged observation time comfortable.

Fast aperture F50/1.0 thermal lens

Fast aperture F50/1.0 thermal lens

The characteristics of thermal imaging optics have a decisive influence on a thermal imager’s ability to capture even the lowest radiation levels. Ultimate detection efficiency is achieved with the fast lens of the Merger Duo (F50/1.0) thermal imager in combination with the highly sensitive thermal sensor. The Merger Duo gives users the best quality, most detailed & high-contrast, informative imagery every time, even during rain or fog, when the temperature contrast of the observed scene is minimal.

Invisible IR Illuminator for image detail increase in digital channel

The Merger Duo NXP50 is supplied with an attachable 940 nm invisible IR illuminator, increasing the image detail in digital channels at night. Three-step power adjustment allows the user to choose their preferred viewing distance and the illumination levels of observed objects. Fine IR spot position control makes it possible to place the highest illumination levels in a desired area of the field of view.

High-contrast HD AMOLED displays

High-contrast HD AMOLED displays

While the Merger’s HD AMOLED displays deliver crisp, richly contrasted, vividly colored field of view, AMOLED technology ensures flawless, fluid, high-resolution image, and power saving.

A selection of 8 colour palettes in thermal mode

A selection of 8 colour palettes in thermal mode

A choice of eight colour palettes enables the user to observe their field of view more effectively, allowing them to optimise the unit for specific tasks as well as react to changing observation conditions. White Hot, Black Hot and Red Hot are optimal for object detection. Rainbow and Ultramarine help increase the chances of recognition & identification. Red Monochrome, Sepia and Violet are best for extended observation at night.

1800m thermal detection range

The advantage of thermal imaging is early animal detection at any time of day. At night, it is the most effective way to find game at a great distance. Due to high-quality long-focal-length optics and a high-sensitivity sensor, the Merger Duo has outstanding capabilities for the observation range – an object with a height of 1.8 m is detected at 1800 meters in complete darkness.

User-friendly

Comfortable viewing experience

Comfortable viewing experience

The Merger binoculars’ optical design fully takes into account the nature of human vision. It is natural for a person to receive visual information through two visual channels simultaneously. Viewing with two eyes is less tiring than viewing with one. This means better detection of small or faint objects, and better performance in low-contrast scenarios than similar monocular thermal imaging devices with the same technical level. The interpupillary distance in the Merger binoculars is adjustable from 62 to 74 mm in accordance with the individual characteristics of a particular user.

Convenient classic binocular design

Merger Duo multispectral binoculars are built with the classic design of daytime binoculars. With a small form factor, these binoculars fit comfortably in the hand, but still offer appealing external aesthetics and exemplary ergonomics. The six function buttons are placed in the comfort access zone and the most used digital device functions are activated with a single touch.

Built-in photo and video recorder

Built-in photo and video recorder

The Merger Duo has a built-in video recorder. The internal memory can store hours of video and tens of thousands of photos. One touch of a button is enough to take a photo of an interesting scene or start recording video.

Dual battery system

The Merger Duo is powered with two rechargeable batteries: one built-in with a capacity of 4 Ah, the other replaceable with a capacity of 3.2 Ah. A single charge guarantees up to 7 hours of battery life. The embossment on the body of the replaceable battery for accurate determination of the correct position makes it possible to quickly and confidently replace a flat battery with a new one in complete darkness by touch.

Ergonomic and functional carrying case

A hunter must be fast-moving. A sign of good quality equipment is being at hand when needed, and invisible the rest of the time. Stylish on the outside, the Merger Duo case is user-friendly and comfortable to carry. The device is quickly and easily removed from the case and placed in position. The system of optimal belt positioning distributes the device weight on the hunter's body, relieving the load from the shoulders, back and neck. The case fits snugly to the body, without preventing the hunter from freely bending, turning, crouching, moving across country and using weapons. Additionally, the case is equipped with straps for attaching it to a waist belt, as well as to equipment with a modular Molle fixation system, including backpacks and webbed gears.

Stream Vision 2. Wi-Fi integration with iOS and Android devices

Stream Vision 2. Wi-Fi integration with iOS and Android devices

Built-in Wi-Fi connects the Merger Duo to Android and iOS smartphones via the Stream Vision 2 mobile application. This opens up a wide range of options including wireless device software updates, real-time image transmission from the device to the smartphone screen, publication on social media of photo and video content captured by the device or transfer to messengers, remote control of digital device functions and access to the latest news from Pulsar. Moreover, registered users receive 16 GB of cloud storage for photos and videos recorded with the device.

Proximity sensor for covert use

Observation in the dark requires being covert, so that hunted animals are not alerted by your presence. Going to stand-by using Display Off feature is a usual way to prevent backlight from the eyepieces. To simplify this task Merger Duo has a built-in proximity sensor. It acts as a display switch for preventing backlight exposure in the dark. When the unit is taken away from the eyes, proximity sensor switches both displays off and when the unit is brought closer both displays are switched on offering excellent image quality.

Dual Wi-Fi waveband support 2.4 / 5 GHZ

Dual Wi-Fi waveband support 2.4 / 5 GHZ

In Merger Duo thermal imagers, the standard smartphone connection frequency range via a 2.4 GHz Wi-Fi channel is complemented with an effective 5 GHz range. The 5 GHz connection offers better bandwidth, a faster data transfer rate, noise immunity and improved connection stability, resulting in more productive and easier operation of the thermal imager with a smartphone.

Rugged and Reliable

Magnesium alloy housing

Magnesium alloy housing

Merger Duo is designed for constant, often hard use. A magnesium alloy housing is light and strong at the same time. The housing reliably protects the internal components of a thermal imaging device from shocks, drops, moisture, heat or cold. At the same time, a metal housing effectively removes the heat from electronics and increases consistency of the device operation during long-term observation.

IPX7 submersion waterproof rated

IPX7 submersion waterproof rated

IPX7 waterproof-rated for protection from heavy rainfall, snow or other precipitation. The unit is designed to run flawlessly, even after submersion in up to 1 meter of water for up to 30 minutes.

Operation in extreme temperatures -25 to +50°C

Operation in extreme temperatures -25 to +50°C

Housing, power unit, optics and electronics of Merger are designed with regard to applications in wide range of temperatures. Merger ensures reliable and effective performance in freezing cold up to -25°C.
