Description
THERMION 2 LRF XP50 Pro Thermal Imaging Riflescope by Pulsar
The first thermal imaging riflescope with classic design and built-in laser rangefinder
The laser rangefinder has been integrated seemlessly into the tube style thermal sight we've all come to expect from Pulsar. The Thermion 2 LRF is compact, the sender & receiver modules are combined into the space of a single optic. The maximum range of the LRF is 800 metres – this is the new normal for the Thermion 2 Pro, where precision visuals and precise measuring meet to come together for that next level hunting experience!
Proposed Uses (XP50 Pro);
- Suitable for: Rifle mounting (30mm rings typically)
- Thermal Detection Range = up to 1800mtrs
- Thermal Identification Range for various sized targets;
- Small (Rabbit) = 150m
- Sml-Med (Fox) = 200m
- Medium (Pig) = 250m
- Med-Lge (Deer) = 350m
Key Features (XP50 Pro);
- 640x480 thermal sensor (17um, NETD <25mK)
- 50mm objective lens (F1.0), 2.0x base magnification (12.4 x 9.3 FoV)
- AMOLED display (1024x768),
- 800mtr Integrated Infrared Laser Rangefinder
- 1x APS2 removeable battery, Internal Li-ion battery (over 5hrs runtime)
- 16Gb onboard storage, media recording (w/Audio), WiFi connectivity (Stream Vision 2 App)
Thermion 2 LRF Specifications;
| Main | Thermion 2 LRF XG50 Pro | Thermion 2 LRF XP50 Pro | Thermion 2 LRF XQ50 Pro |
|
Sensor
|
640x480 @ 12µm (NETD <25 mK)
|
640x480 @ 17µm (NETD <25 mK)
|
384x288 @ 17µm (NETD <25mK)
|
|
Objective lens
|
F50/1.0 | F50/1.0 | F50/1.0 |
|
Magnification, x
|
3 – 20 (x8 digital)
|
2 – 16 (x8 digital)
|
3 - 12 (x4 digital)
|
|
Field of view (HxV), degrees / m@100m
|
? tba
|
12.4x9.3 / 21.8x16.3
|
7.5 / 13.1
|
|
Detection range, m
|
1800
|
1800
|
1800
|
|
Sensor
|
|||
|
Type
|
uncooled
|
uncooled
|
uncooled
|
|
Resolution, pixels
|
640x480
|
640x480
|
384x288
|
|
Pixel pitch, µm
|
12
|
17
|
17
|
|
NETD, mK
|
<25
|
<25
|
<25
|
|
Frame rate, Hz
|
50
|
50
|
50
|
|
Optics
|
|
|
|
|
Objective lens
|
F50/1.0
|
F50/1.0
|
F50/1.0
|
|
Magnification, x
|
3 - 20
|
2 - 16
|
3 - 12
|
|
Field of view (HxV), degrees / m @ 100 m
|
? tba
|
12.4x9.3 / 21.8x16.3
|
7.5 / 13.1
|
|
Eye relief, mm
|
? tba
|
50
|
50
|
|
Display
|
|
|
|
|
Type
|
? tba
|
AMOLED HD
|
AMOLED
|
|
Resolution, pixels
|
? tba
|
1024x768
|
1024x768
|
|
Range Performance
|
|
|
|
|
Detection range, m
|
1800
|
1800
|
1800
|
|
Laser Rangefinder
|
|
|
|
|
Safety Class for laser equipment according IEC 60825-1:2014
|
1
|
1
|
1
|
|
Wavelength, nm
|
905
|
905
|
905
|
|
Max. measuring range, m
|
800
|
800
|
800
|
|
Measurement Accuracy, m
|
+/- 1
|
+/- 1
|
+/- 1
|
|
Reticle
|
|
|
|
|
Click value, H/V, mm at 100 m
|
21 / 21 (on minimum magnification)
|
21 / 21 (on minimum magnification)
|
13 - 3x 6.5 - 6x 3.25 - 12x
|
|
Click range, H/V, mm at 100 m
|
4200 / 4200
|
4200 / 4200
|
2600 / 2600
|
|
Number of preloaded reticles
|
10+
|
10+
|
10
|
|
Video Recorder
|
|
|
|
|
Video / photo resolution, pixel
|
1024x768
|
1024x768
|
1024x768
|
|
Video / photo format
|
.mp4 / .jpg
|
.mp4 / .jpg
|
.mp4 / .jpg
|
|
Built-in memory, Gb
|
16
|
16
|
16
|
|
Wi-Fi
|
|
|
|
|
Wireless Protocol
|
Wi-Fi
|
Wi-Fi
|
Wi-Fi
|
|
Wireless Standard
|
IEEE 802.11 b/g/n/ac
|
IEEE 802.11 b/g/n/ac
|
IEEE 802.11 b/g/n/ac
|
|
Frequency, GHz
|
2.4 / 5
|
2.4 / 5
|
2.4 / 5
|
|
Bluetooth
|
|
|
|
|
Wireless Protocol
|
BLE 4.2
|
BLE 4.2
|
-
|
|
Wireless Standard
|
IEEE 802.15.1
|
IEEE 802.15.1
|
-
|
|
Frequency, GHz
|
2.4
|
2.4
|
-
|
|
Environmental Characteristics
|
|
|
|
|
Degree of protection, IP code (IEC60529)
|
IPХ7 (waterproof) | IPХ7 (waterproof) | IPХ7 (waterproof) |
|
Operating temperature range, °C
|
-25 – +50
|
-25 – +50
|
-25 – +50
|
|
Connections and Compatibilities
|
|
|
|
|
Max. recoil power on rifled weapon (Eo), Joules
|
6000
|
6000
|
6000
|
|
Shock resistance on the smooth-bore rifles, caliber
|
12
|
12
|
12
|
|
Mounting brackets on weapon
|
Standard 30 mm rings
|
Standard 30 mm rings
|
Standard 30 mm rings
|
|
Remote Control
|
Pulsar BT (optional)
|
Pulsar BT (optional)
|
-
|
|
Supported Appplication
|
Stream Vision 2
|
Stream Vision 2
|
Stream Vision 2
|
|
Power Supply
|
|
|
|
|
Output voltage, V
|
3.0 - 4.2
|
3.0 - 4.2
|
3.7v
|
|
Battery type
|
? tba
|
Dual Li-Ion B-Pack Mini Power System: 2 A·h Changeable Battery (external) / 4.9 A·h Battery (internal)
|
Li-ion Battery Pack APS2
|
|
Capacity, mAh
|
? tba
|
2000 (external) + 4900 (internal)
|
4900
|
|
Operating time on battery pack (at t=22°C), h *
|
? tba
|
10
|
10
|
|
External power supply, V
|
USB type C (5V)
|
USB type C (5V)
|
5V, 9V (USB Type-C Power Delivery)
|
|
Weight & Size
|
|
|
|
| Body Material |
Aluminium alloy
|
Aluminium alloy
|
Aluminium alloy
|
|
Dimensions mm
|
? tba
|
420x78.5x94.5
|
420x78.5x94.5
|
|
Weight kg
|
? tba
|
0.97
|
0.97
|
|
Warranty
|
|
|
|
|
Warranty on Device, years
|
3
|
3
|
3
|
|
Warranty on Batteries, years
|
1
|
1
|
1
|
|
Trade Data
|
|
|
|
|
SKU (Model #)
|
76554 | 76551 | 76555 |
Optoelectronic Devices & Batteries Compatibility Chart
Extra Information
Warranty Information
Pulsar Products have a 3 year warranty with the exception of Pulsar batteries which have a warranty of 1 year from purchase.
